Electrostatic Discharge Ionizer
Horizontal Electrostatic Discharge Ionize
1️⃣ Working Principle
The 1000A Horizontal Ionizing Fan generates a large volume of positive and negative ionized airflow to neutralize static electricity on objects.
If an object's surface has a negative charge, it attracts positive ions from the airflow.
If an object's surface has a positive charge, it attracts negative ions, effectively eliminating static electricity.
This prevents static-related issues such as dust attraction, plastic adhesion, and small component repulsion in manufacturing.
The fan features an axial flow fan to distribute airflow, with an adjustable speed control for a wide range of applications.
The ionization device operates under high voltage and low current, creating a stable high-voltage field to ionize air and generate ionized particles. A built-in ion emitter cleaner removes dust from ionization needles to maintain optimal performance.
2️⃣ Electrostatic Discharge Ionize's Key Features
✅ Rapid Static Neutralization – Quickly eliminates electrostatic charges.
✅ Wide Ionized Airflow Coverage – Ensures large working area protection.
✅ Adjustable Airflow Speed – Flexible settings to match application needs.
✅ Stable Ion Balance – Optional ion balance regulator for precise control.
✅ Integrated Ion Emitter Cleaner – Keeps ion needles free of dust for optimal efficiency.
✅ Ionization Indicator – Displays operational status for easy monitoring.
✅ Optional Cooling & Heating Function – Customizable for different environments.
✅ Optional Air Filter – Ensures clean, particle-free ionized airflow.
✅ Adjustable Airflow Angle – Enhances adaptability to different workstations.
✅ Grounding Protection – Ensures safe operation and reliable static control.
3️⃣ Electrostatic Discharge Ionize's Technical Specifications
| Specification | Details |
|---|---|
| Power Consumption | 50W / 250W (with heating function) |
| Input Voltage | 220V/50Hz or 110V/60Hz |
| Output Voltage | AC 5.6KV |
| Ion Balance | ≤±10V |
| Airflow Output | ≤3.3m³/min |
| Effective Ionization Area | 590mm × 1800mm |
| Ozone Emission | <0.03PPM (measured 15cm from the fan) |
| Noise Level | 50dB |
| Operating Temperature | 0°C to 50°C |
| Dimensions (Without Stand) | 390mm (L) × 210mm (W) × 115mm (H) |
| Dimensions (With Stand) | 450mm (L) × 210mm (W) × 190mm (H) |
| Weight | Approx. 7.3kg (Net) |
| Housing Material | Cold-rolled steel |
| Surface Treatment | Painted finish |
4️⃣ Electrostatic Discharge Ionize's Test Results
Test Conditions:
Test Voltage: 1KV → 100V
Environment Temperature: 22°C
Humidity: ≤60%
| Test Distance | Left 300mm | Center | Right 300mm |
|---|---|---|---|
| 300mm | 1.1s | 1.0s | 1.1s |
| 600mm | 2.2s | 2.2s | 2.2s |
🔹 Static elimination time and ion balance voltage meet ESD standards.
🔹 Data tested using ME268A Electrostatic Comprehensive Tester.
🔹 Results may vary depending on ambient temperature and humidity.
5️⃣ Electrostatic Discharge Ionize's Applications
📌 Electronics Manufacturing – Prevents static damage to PCBs, IC chips, and semiconductors.
📌 Precision Instrument Assembly – Eliminates dust attraction and electrostatic issues.
📌 Plastic & Optical Manufacturing – Prevents adhesion problems caused by static electricity.
📌 Cleanrooms & Laboratories – Maintains a static-free controlled environment.
📌 Printing & Coating Industry – Ensures even printing and uniform coating application.
