The 1001B single-head AC ion fan is a dedicated device for eliminating static electricity. It is an automatic cleaning model in the Jinghao ion fan series. The single-head AC ion fan is designed as a desktop unit, featuring easy installation, stable operation, and rapid static electricity elimination. It can provide an overall neutralization effect of static electricity on the working surface used by an operator. The JH1001B single-head ion fan can generate a large amount of air flow with positive and negative charges, which can neutralize the charges on objects. When the surface of an object carries a negative charge, it will absorb the positive charges in the air flow; when the surface of an object carries a positive charge, it will absorb the negative charges in the air flow, thereby neutralizing the static electricity on the object's surface and achieving the purpose of eliminating static electricity. The JH1001B single-head ion fan is equipped with a small fan to provide air force, and the strength of the air force can be adjusted within a wide range by a speed control switch. The ionization device of the JH1001B single-head ion fan: Under the action of high voltage and low current generated by the high-voltage generating device, the ionization device forms a stable high-voltage electric field, ionizing the air to form an ionized gas, which is carried by the air flow to the surface of the object, achieving the purpose of neutralizing static electricity. There is a dedicated cleaner on the ionization device that can remove the dust accumulated on the ionization needle, ensuring the normal operation of the ionization device. The static electricity elimination function of the JH1001B single-head ion fan can solve production problems caused by static electricity, such as dust attraction issues, adhesion problems during plastic product processing, and small parts jumping due to electrostatic repulsion.
Product characteristics
1. Small size, light weight, portable design, Angle gear design, can be adjusted 180 degrees.
2. Quickly neutralize static electricity.
3. The ion airflow covers a large area.
4. Wide range of wind regulation.
5. The ion balance is stable, and the ion regulator can be installed if necessary.
6. Automatic ion emitter cleaner.
7. Have an ionization indicator.
8. Cold air heating device can be installed if necessary.
9. Filter can be installed if necessary.
Technical Parameters:
Power: < 30W
Input Voltage: 220V/50Hz
Consumption Current: 3A (at maximum wind speed)
Low Speed: 60 CFM, 2.5 m/s
High Speed: 150 CFM, 6.0 m/s
Effective Coverage: 300mm × 300mm × 900mm
Ozone Content: < 0.03 PPM (measured 15 cm in front of the ion fan)
Operating Temperature: -10°C to +50°C
Dimensions (without bracket): 154mm (L) × 85mm (W) × 228mm (H)
Dimensions (with bracket): 215mm (L) × 100mm (W) × 242mm (H)
Residual Voltage: < ±10V (test distance: 300mm - 600mm)
Weight: 2.7kg
Shell Material: Cold-rolled steel plate, surface painted.
Electrostatic discharge test results:
Test conditions Test voltage: 1kv - 100v
Ambient temperature: 22℃
Humidity: <60%
Test distance: 300mm, 600mm
Positive: 0.3s, 0.9s
Neutralization time Negative: 0.3s, 0.7s
Positive residual voltage: < +10٧
The ion balance voltage and electrostatic discharge time of the single-head AC ion blower comply with ESD standards. The electrostatic discharge time is measured from a test voltage of 1000v to 100v. * Test data is subject to the results of the ME268A electrostatic comprehensive tester. * Test data may vary due to changes in the temperature and humidity of the surrounding air.
